Industrial 1000kW Silent Generator Set with Yuchai Engine for Reliable Backup Power

Industrial 1000kW Silent Generator Set with Yuchai Engine for Reliable Backup Power

Merknaam:	Yuchai engine
Modelnummer:	MB-1000
MOQ:	1 st
Prijs:	Price:Negotiable
Betalingsvoorwaarden:	Western Union, T/T, D/P, L/C
Toeleveringsvermogen:	200 stks/maand

Gedetailleerde informatie

Productbeschrijving

Gedetailleerde informatie

Plaats van herkomst:

China

Certificering:

ISO 9001:14000,CE,EACC

Merknaam::

YUCHAI-diesel generator

Nominale spanning::

230V/400V

Motormodel::

YC6TF1520-D31

Nominale stroom::

1800A

Frequentie::

50 Hz/60 Hz

Alternatormerk::

MBKL / WUXI Standford / Stamford / Leroy-Somer

Bedieningspaneel::

Deepsea / Harsen / SmartGen

Certificaat::

ISO 9001: 14000, CE

ATS::

Optioneel

Levering::

7-30 dagen

Garantietijd::

1 jaar of 1000 looptijd (welke eerst aankomen)

Snelheid::

1500 tpm/1800 tpm

Verpakking Details:

Plastic gewikkeld op houten dragers als consumentenvereisten. LCL, 20ft en 40ft zijn beschikbaar.

Levering vermogen:

200 stks/maand

Productbeschrijving

Yuchai YC6TF1520-D31 diesel generator sets features:

(1) . Full control panel with power indicator light and oil light.
(2). Emergency shutdown for low oil pressure and high water temperature.
(3). Large fuel tank ensure continuous running.
(4). Low noise & vibration.
(5). Compact structure.
(6). Reliable performance.
(7). Easy for installation and maintenance.

Painting materials
rust removing in pickling tank(10minutes)------unoil(30mins)-----rinsing(3mins)----wathsetting(10mins)----rinsing(5mins)-----parkerising(20mins)----rinsing----blow dry-----stoving----pylons----spray paint(adopt static flame paint)-----Oven(170degree/20mins)-----draw a charge---inserting coil.

Genset
Model	MB-1000
Output Power	1000KW/1250KVA
Power Factor	COSΦ=0.8( lagging)
Maximum Output Current	1800A
Silent type Weight	9150 kg
Silent type Dimensions	580024002900
Voltage	400/230V
Frequency	50Hz
Diesel Engine
Manufacturer	Yuchai Diesel Engine
Model	YC6TF1520-D31
Rotate Speed	1500RPM
Power	1118 kW
Fuel Consumption	≤195 g/kw.h
Lubricating oil capacity	95L
Cylinder/Stroke	152mm/200mm
Compression Ratio	13.5:1
Displacement	31.75L
Configuration	6-cylinder In-line, four-stroke, water-to-air cooling
Cooling Mode	Liquid Cooled
Speed Control System	Electronic
Starting Mode	24V DC
Filter System	Dry air filter, fuel filter, oil filter
Alternator
Manufacturer	Changsha Mingbang Intelligent Technology Co.Ltd
Model	MBV6F
Voltage Control Mode	AVR (automatic voltage regulation)
Voltage Regulation	±1%
Rated Voltage/Frequency/Power Factors	400V/230V, 50Hz, COSΦ=0.8 lagging, three-phase four-wire
Steady State Frequency	Better than 5%
No-load Voltage Adjust Range	≥95% - 105%
Insulation Class/Protection Class	H / IP22
Excitation Type	Brushless

Industrial 1000kW Silent Generator Set with Yuchai Engine for Reliable Backup Power 0

Our factory

Mingbang Power Perkins Diesel Generating Set, power ranging from 45kVa up to 2250kVa. Perkins is the world's top engine brand, for more than 80 years, UK Perkins has been the world's leading supplier of diesel and gas engines in the 4 - 1800 kW market. Perkins key strength is its ability to tailor engines precisely to meet customers' requirements, which is why its engine solutions are trusted by more than 1,000 leading manufacturers in the industrial, construction, agricultural, materials handling and electrical power generation markets.

Our factory has CCEC, DCEC, PERKINS,MTU,Deutz, Daewoo, SDEC, Weichai,Jichai etc. World and Chinese famous engine for generators set. We have specialized in synchronous 100%copper wire alternator for more than 20 years. MB brand alternator has been expanded all over the world. The power range of our generator is from 6.5KW~2000KW.

Industrial 1000kW Silent Generator Set with Yuchai Engine for Reliable Backup Power 3

New Powered By Yangdong Engine Prime Power 800kw Diesel Generator Set

Industrial 1000kW Silent Generator Set with Yuchai Engine for Reliable Backup Power 4

More details for diesel generator sets ,please contact us any time

Your further inquiry will be welcome!!
